Buy FreeScan UE Pro2 Portable 3D Metrology Scanner
The new FreeScan UE Pro2 3D scanner from Shining 3D is a portable and fast industrial scanner based on the previous generation of the FreeScan UE Pro.
The new scanner is extremely accurate, productive and versatile, and is suitable for applications that require maximum scanning quality and speed.
Key Features
- Wireless
- Ultra-high scanning speed up to 3,460,000 dots/second
- Patented binocular photogrammetry
- Fast on-site review
FreeScan UE Pro2 features an innovative integrated wireless module for greater freedom and mobility. With ultra-fast scanning speeds, efficiency is doubled, allowing projects to be completed faster.
The patented built-in innovative photogrammetry improves measurement accuracy, making it ideal for scanning a wide range of parts, from small to large. In addition, the integrated inspection module facilitates on-site quality control, easily streamlining your workflow with a complete manufacturing solution.
The ideal tool for inspection and versatile applications, the FreeScan UE Pro2 sets a new standard in the world of portable metrology.
Double the speed and productivity
FreeScan UE Pro2 offers scanning efficiency almost double that of the previous generation.
With high scanning speeds of up to 3,460,000 dots/second, you can complete scanning jobs with ease. Focus on inspection performance, not the technical limitations of the equipment.
- Built-in computing module. Accelerates data capture and processing, reducing scan time and computer workload by providing wireless scanning mode to achieve the same frames as a cable-connected scanner.
- 50 laser lines. Provide faster and more comprehensive scanning.
- High frame rate. Reaches 180 frames per second for smooth and fast data acquisition.
Increased accuracy for large-scale scanning
FreeScan UE Pro2 features innovative built-in binocular photogrammetry technology for large-scale scanning, quickly optimizing the spatial position of global markers for consistent accuracy. Unlike traditional photogrammetry methods, our binocular photogrammetry eliminates the use of coded markers, reducing preparation time by at least half while maintaining the same high level of measurement accuracy.
Fast and accurate scanning of large and small parts
The industrial scanner provides high-quality data for further work on objects of varying complexity.
The Shining 3D FreeScan UE Pro2 is twice as fast, and it handles even complex surfaces. It confidently passes all depressions and curves.
Indoor and outdoor scanning
The FreeScan UE Pro2 works well both indoors and outdoors, making it versatile for any working environment.
Thanks to its small size, convenient geometry and light weight, the device can even be used outdoors. For greater autonomy, the device has a built-in power supply.
Certified and guaranteed results
With volumetric accuracy down to 0.02 mm + 0.015 mm/m using photogrammetry, the FreeScan UE Pro2 provides consistent and reliable accuracy and scanning results.
The SHINING 3D Accuracy Lab, accredited by CNAS to ISO 17025, provides thorough optical metrology calibration.
Based on VDI/VDE 2634 guidelines, the laboratory guarantees traceability of measurement processes and calibration results.
This certified metrology system is ISO compliant and can be easily integrated into ISO quality control processes.
Universal scanner for different applications
The scanner can be used for different applications thanks to its 3 functions.
- 50 laser lines allow for truly high-speed scanning.
- 7 parallel laser lines are responsible for detailed data.
- 1 laser line scans deep holes.
FreeScan Software
Intuitive and powerful software
- Real-time mesh data display. Simplified software displays real-time mesh data during the scanning process, improving visual quality and saving time creating a mesh later.
- Customized Scan Template. Save time and ensure consistency by customizing your own scanning template. No need to set parameters manually.
- Data Property Visualization. Users can control the scanning distance by the color of the laser lines or LED indicator and evaluate the data quality with a real-time grid indicator.
- Flexible resolution. EXScan allows you to change the resolution later to suit your needs without restarting the project.
Specifications
| Light Source | 50 laser lines (Multiple Lines Scan), 7 parallel laser lines (Fine Scan), one laser line (Single Line Scan) |
| Volumetric Accuracy (mm/m) | 0,02 + 0,03 |
| Volumetric Accuracy with Photogrammetry (mm/m) | 0.02 + 0.015 |
| Scanner Type | Handheld |
| Additional Extensions | No |
| Color Scanning | No |
| Scan With Marks | Yes |
| Scan Mode | High-speed Scanning – 50 laser lines. Detailed Scan – 7 parallel laser lines. Deep Pockets – 1 single line |
| Safety Class | Class 2M (safe for eyes) |
| Part Size Range (m) | Large to small |
| Scanning Speed (points/s) | 3 460 000 |
| Scan Accuracy (mm) | Up to 0,02 |
| Scan Range (mm) | 600 × 550 |
| Stand-Off Distance (mm) | Multiple Lines Scan – 300; Fine Scan – 200; Single Line Scan – 300 |
| Scan Depth (mm) | 360 |
| Point Distance (mm) | 0,01 – 10 |
| Additional Information | Compatible with multiple inspection and 3D design software solutions such as Geomagic Design X, Geomagic Control X, Polyworks Inspector |
| Features | Built-in scale bar photogrammetry mode, temperature sensor, deep hole and dark&reflective parts scanning |
| Connectivity | USB 3.0 |
| Power Requirements | 24V, 3.75A |
| System Requirements | OS: Windows 11 Professional 22H2 (64-bit). Processor: 13th Gen Intel® Core™ i7-13700H or higher. Graphics: NVIDIA GeForce RTX 4060 Laptop GPU or higher. Video Memory: 8 GB or higher. RAM: 64 GB or higher, dual-channel DDR5; USB 3.0 interface |
| Manufacturer Country | China |
| Warranty Period (months) | 12 |
| Certifications | CE, FCC, ROHS, WEEE, KC, FDA, UKCA, IP50, TELEC, TISAX. Accuracy Certification: VDl/VDE 2634 Part3 (certificated in ISO 17025 certificated accuracy lab) |
| Weight Netto (kg) | 0,950 |
| Dimensions Netto (mm) | 305,8×118,9×100,8 |
| Operating Temperature Range (°C) | -20 – +40 |
| Operating Humidity Range (%) | 10 – 90 |
