Shining 3D FreeScan UE Pro Multifunctional Laser 3D Scanner
Introducing the Shining 3D FreeScan UE Pro, a multifunctional handheld laser scanner.
Based on the FreeScan UE, this new generation of scanner inherits metrological accuracy and high data detail in a user-friendly ergonomic design, while improving precision scanning capabilities and global accuracy control when scanning large-scale objects.
The scanner operates in multiple scanning modes, utilising 26, 5 or 1 blue laser line projection and photogrammetric module integration.
Features of Shining 3D FreeScan UE Pro
- High precision metrology inspection
- High accuracy down to 0.02mm, delivers consistently high quality scan results.
Global accuracy control
The FreeScan UE Pro scanner features a patented inbuilt scale bar. The integrated photogrammetry does not require the location of encoding points, quickly capturing the spatial position of the target wireframe. The photogrammetry module improves volumetric accuracy to 0.02 + 0.015 mm/m.
Multiple scanning modes
The scanner projects 26 crossed blue laser lines for fast scanning of large objects, 5 parallel laser lines for refined scanning and one laser line for precise scanning of deep holes and narrow areas.
Easy to operate
Inheriting the lightweight and ergonomic design of the UE series, the intuitive user interface provides easy operation and reduces training time. A low working distance of 300mm compared to competitors and a wide scanning range of 600*500mm, allows fast surface digitisation in hard-to-reach areas.
Wide range of material adaptation
Support scanning black and highly reflective surfaces, deep holes, ribbed surfaces, large and small objects.
Fine and rich details
With high-resolution cameras and 5 parallel laser lines, FreeScan UE Pro provides feature-rich object scanning and more accurate recovery of fine details.
FreeScan UE Pro 3D Scanner Applications
Considering speed, accuracy and detail, FreeScan UE Pro is a professional volumetric metrology solution that is suitable for inspection scanning, CAD design, reverse engineering, ultra-precise measurement, convenient digital replication of any object, including dark and mirrored surfaces, large, medium and small objects, complex geometries with pockets and pits.
FreeScan UE Pro is a complete, accurate and affordable hardware and software suite for design, quality management and control, inspection and analysis, adjustment and repair in the automotive, aerospace, energy, transport, manufacturing and engineering industries.
Software
Supplied with specially developed Shining 3D software. Free updates and support for upgrades.
Compatible with 3D design software: Solid Edge, Geomagic Design X, Geomagic Essentials. And 3D inspection software: Geomagic Control X, Geomagic Control X Essentials. Easy and smooth data import into these programmes improves workflow efficiency and adds versatility to the scanner.
FreeScan UE Pro Specifications
| Light Source | Blue laser, 26 laser lines, 5 parallel lines, 1 line |
| Volumetric Accuracy (mm/m) | 0.02 + 0.03 |
| Scan Range (mm) | 600 × 550 |
| Working Distance (mm) | 300 |
| Scanner Type | Handheld |
| Color Scanning | No |
| Marker Scanning | Yes. Built-in photogrammetry does not require positioning markers |
| Scan Mode | Multiple Lines Scan, Single Line Scan, Fine Scan |
| Part Size Range (m) | Large, medium and small |
| Scan Speed (points/s) | 1,850,000 |
| Scan Speed (frames/s) | 180 |
| Scan Accuracy (mm) | Up to 0.02 |
| Volumetric Accuracy with DigiMetric (mm/m) | 0.02 + 0.015 |
| Scan Depth (mm) | 170 – 680 |
| Point Distance (mm) | 0.01 – 3 |
| Additional Information | Compatibility with multiple software solutions for control and 3D design, such as Solid Edge, Geomagic Design X, Geomagic Essentials, Geomagic Control X, Geomagic Control X Essentials |
| Laser Class | Class 2M (eye-safe) |
| Features | Built-in photogrammetry mode with scale, temperature sensor, deep hole scanning, dark and reflective part scanning |
| Supported File Types | OBJ, STL, ASC, PLY, P3, 3MF |
| Connectivity | USB 3.0 |
| Input Power | 12V, 5.0A |
| System Requirements | OS: Win10, 64-bit; Graphics Card: NVIDIA GTX/RTX series cards above or equal to GeForce RTX 3060; Video Memory: ≥ 6 GB; Processor: I7-8700; Memory: ≥ 32 GB |
| Country of Origin | China |
| Warranty Period (months) | 12 |
| Certificates | CE, FCC, ROHS, WEEE, RC |
| Net Weight (kg) | 0.840 |
| Net Dimensions (mm) | 298×103.5×74.5 |
| Operating Environment Temperature Range (°C) | -20 – +40 |
| Operating Environment Humidity Range (%) | 10 – 90 |
Universal 3D scanner FreeScan UE Pro
Scanning a two-seat aircraft with the FreeScan UE Pro scanner in photogrammetry mode
Specification
| Device Model | FreeScan UE Pro | |
|---|---|---|
| Scanning Mode | Multiple lines scan, Single line scan | Fine scan |
| Light Source | 26 laser lines + 1 single laser line | 7 parallel laser lines |
| Scanning Accuracy | Up to 0.02 mm | |
| Scanning Speed | 1,850,000 points/s | |
| Working Distance | 300 mm | 200 mm |
| Depth of Field | 170 mm ~ 680 mm | |
| Max. Scan Area | 600 mm × 550 mm | |
| Point Distance | 0.01 - 10 mm | |
| Photogrammetry | Built-in photogrammetry mode with scale bars | |
| Volumetric Accuracy* | 0.02 + 0.03 mm/m (standard mode); 0.02 + 0.015 mm/m (built-in photogrammetry mode) | |
| Laser Class | Class II (eye-safe) | |
| Connection Standard | USB 3.0 | |
| Dimensions | 298 mm × 103.5 mm × 74.5 mm | |
| Weight | 840 g | |
| Power Input | 12 V, 5.0 A | |
| Operating Temperature | -20 ~ 40°C | |
| Operating Humidity | 10 ~ 90% | |
| Certification | CE, FCC, ROHS, WEEE, KC, FDA, UKCA, IP50, TELEC, TiSAX | |
| Accuracy Certification | VDI/VDE 2634 Part 3 (certified in an ISO 17025 accredited metrology lab) | |
| Recommended PC Configuration |
OS: Windows 10 (64-bit); Graphics Card: NVIDIA GTX/RTX series (GeForce RTX 3060 or higher); VRAM: ≥ 6 GB; Processor: Intel Core i7-8700; RAM: ≥ 32 GB |
|
