3D scanning liquid spray AESUB Yellow, 200 ml, for air brush

Description

AESUB Yellow 3D scanning spray

AESUB Yellow 3D scanning liquid spray was developed by scanning experts for use with airbrushes. It eliminates the main problems of using optical scanners when scanning shiny and transparent objects. After being sprayed onto the surface, it creates an ultra-thin matte finish and then evaporates after a while without additional cleaning.

Features of AESUB Yellow matting liquid

• A modern tool for 3D scanning.
• Solution for use in an airbrush.
• Ultra-thin and homogeneous coating – less than 1 µm.
• Matte coating disappears after 4-6 hours.
• Ideal for scanning parts with the highest accuracy
• Pigment-free – does not contain titanium dioxide.
• No cleaning is required.
• For use in 3D metrology, especially in sensitive areas

Buy AESUB Yellow 3D scanner fluid

The spray leaves no traces on the surface of the object after scanning and evaporation. Thus, it is used in those conditions where it is important to treat the scanned object with care or it is important not to leave a coating on the surrounding devices and equipment.

AESUB Yellow is suitable for use in 3D metrology, especially in sensitive areas (laboratories, manufacturing, etc.), and protects equipment from contamination by pigment deposits. Forget about the costly transportation of externally coated measurement objects to the sensor and the time-consuming cleaning of the measurement environment and objects after scanning.

With AESUB yellow, you achieve a significant increase in the efficiency and productivity of the entire digitization process.

How to use the 3D scanning spray

• Spray the spray evenly onto the object to be measured from a distance of 5-10 cm.
• Scan the object as usual after the spray has dried.
• The applied AESUB layer evaporates automatically in 4-6 hours after spraying.

Characteristics of AESUB Yellow

• Spraying distance – 5-10 cm.
• Effective scanning time – 2-4 hours.
• Coverage – disappearing.
• Evaporation time – 4-6 hours.
• Color – white.
• Pigment content – none.
• Titanium dioxide content – none.
• The layer thickness is 0.5-1.0 microns.
• Can be used with scanning tags – yes.
• Coverage area – 2 m².
• Shelf life – 5 years.

Storage conditions

Store AESUB Yellow in an upright position in a cool, dry place. Avoid storage in direct sunlight.

Download files:

AESUB sprays comparison (EN)

Technical Data Sheets TDS (EN)

Safety Data Sheets SDS (EN)

Buy AESUB matt coating for 3D scanning
