xTool Duct Fan IF2 2.0 – Powerful Inline Fan for xTool Laser Engravers
The xTool SafetyPro IF2 2.0 inline fan is a professional solution for extracting smoke, steam, and odors during laser cutting and engraving. Distinguished by its compactness and power, it is specially designed for optimal ventilation of the workspace and connection to xTool line machines. If you need an inline fan for a laser machine, the xTool IF2 2.0 inline fan, or an xTool smoke extraction fan, this accessory will become a key element of your workshop's ventilation system.
Why you need the xTool IF2 2.0 Inline Fan
When working with laser machines, an increased amount of smoke, aerosols, volatile substances, and odors arises, which must be effectively removed from the working area. A standard exhaust fan often cannot cope with the task during batch processing or long cycles. The xTool IF2 2.0 inline fan provides highly effective extraction through the air duct — it integrates into the exhaust system and ensures stable air movement. This guarantees a clean environment, operator safety, reduced accumulation of contaminants, and prolonged machine service life.
Properties and Features of the xTool Inline Fan
- Dual Fan TurboBoost: two impellers, operating at 14,000 rpm each, provide powerful airflow.
- 55W brushless motor, which ensures high efficiency and reliability.
- Compact housing: a dimensional arrangement that is approximately 5.5 times smaller in volume than analogs.
- Smart control: Auto-On/Off mode, synchronization with the laser machine, selection of the optimal ventilation mode depending on the material.
- High pressure difference created: up to ~1300 Pa.
- Ease of maintenance: modular design, multi-use cleaning (can be washed with water), and easy installation.
- Dimensions and Weight: approximate housing dimensions ~193 × 115 × 119 mm, weight ~2.76 kg.
- Air duct connection diameter 3″ (≈76 mm) with a flexible ~2.3 m PP-hose; suitable for connection to laser machines with such an exhaust pipe.
Purpose and Scope of Application
The xTool IF2 2.0 fan is ideal for small and medium-sized production, laser cutting and engraving workshops, where stable smoke extraction and air purification are required. It is suitable for xTool line machines (e.g., P2 S, S1, M1 Ultra, F1 Ultra) and can be used where a laser cutting fan, xTool laser machine smoke extraction, or an xTool inline duct fan are important. It is especially relevant when processing acrylic, plywood, MDF, textiles, and other materials that produce a significant amount of smoke and odors.
Advantages and Benefits for the User
Using the fan reduces the risk of smoke and odor accumulation in the room, helps maintain a clean working environment, and extends equipment longevity. Thanks to the smart control system, manual intervention is reduced: "the fan automatically turns on and off with the laser." The compact size allows the fan to be installed even in limited spaces. High efficiency (dual fan + powerful motor) ensures better air extraction compared to traditional, lower-power models. This means less downtime, less cleaning, and fewer maintenance costs. Furthermore, a clear connection to the material improves safety and quality.
How to Integrate and Maintain the xTool Duct Fan IF2 2.0 Air Purification Module
Installation requires connection to a 3″ diameter air duct and positioning the fan in such a way as to ensure the most direct exhaust path with minimal bends. It is recommended to select Auto mode if your machine model supports synchronization, or manual speed adjustment for other machines. To maintain efficiency, it is important to regularly clean the housing and impellers — the design allows for quick removal and washing. A user review indicates easy cleaning with water thanks to the water-resistant housing.
Technical Parameters xTool Duct Fan IF2 2.0
| Characteristic | xTool SafetyPro™ IF2 2.0 | First Generation Fan |
|---|---|---|
| Compatibility | All xTool laser machines except MetalFab | P2S, P2, S1, F1 Ultra, D1 |
| Product Dimensions | 182 × 125 × 129 mm | 306 x 255 x 214 mm |
| Product Weight | 1.15 kg | 2.14 kg |
| Air Flow | Approximately 238 m³/h | Approximately 697 m³/h |
| Suction Power | 1300 Pa | 442 Pa |
| Smart Control | Yes | No |
| Fan Speed Settings | 4 speeds | Continuous speed regulation |
| Rated Power | 55 W | 40 W |
If your workshop uses a laser machine and you are looking for a reliable inline fan for a laser machine,
the xTool IF2 2.0 inline fan is what you need! It is an investment in quality, safety, and productivity.
It provides powerful ventilation, smart control, compactness, and ease of maintenance.
When choosing and installing ventilation for laser cutting, it will become a key element of your infrastructure,
allowing you to work comfortably, safely, and efficiently.
