Closed Diode Laser Cutter-Engraver xTool S1 20W
On this page you can buy a laser cutter and engraver xTool S1 20W at one of the most affordable prices in the 3DDevice store.
Safe and efficient, the xTool S1 20W features a closed case and a powerful 20W diode laser. It is an indispensable tool for DIY enthusiasts and professionals, helping to realize creative ideas safely and efficiently. Modern technology and excellent performance of the xTool S1 are now at the service of your creative business.
Main Features of xTool S1 20W
- Laser power: 20 W.
- Efficient engraving speed: up to 600 mm/s.
- Dynamic focus engraving for curved surfaces.
- Rotary engraving at 360°.
- Two-point positioning for 100% accuracy.
- Large working area: 498 × 319 mm.
- One-click autofocus.
- Class 1 Laser Safety Certificate.
- Easily replaceable laser modules.
- Multi-functional software support: XCS and Lightburn.
Safety and Gas Exhaust System
The xTool S1 20W has a fully closed integrated design with a fireproof shell. A transparent cover with two-layer filtration protects your eyes, eliminating the need for protective glasses while allowing you to observe the process.
The design includes a powerful smoke vent equipped with a strong active fan. Harmful gases and smoke generated during operation are quickly exhausted to the outside, ensuring your safety and health.
Four-level Safety Protection
- 5-way flame sensor system: Additional detection capabilities via 4 baffles and the laser head.
- Lid & Base sensors: Automatic emergency stop if the lid is opened during operation.
- Tilt/Impact detection: Processing stops automatically if the device is moved or tilted.
- Emergency Button: Conveniently located for manual stop at any time.
High Power and Efficiency
Using laser compression technology, eight 6W laser beams are compressed into a single 20W beam. This achieves cutting efficiency comparable to CO2 machines, allowing you to cut up to 18mm thick solid wood.
The xTool S1 is compatible with different modules, including the 1064nm laser head, providing unlimited processing possibilities for wood, leather, stainless steel, precious metals, and acrylic.
Advanced Positioning and Focus
TwinPoint Positioning: The new encoder system generates a precise coordinate layout represented visually in the software. The laser head position is displayed in real-time, unifying the physical and virtual worlds.
Dynamic Focus: The advanced intelligent focus system allows for multi-point focusing on 3D objects. The electric Z-axis dynamically adjusts focus for perfect engraving on curved surfaces.
Expand Your Potential
- Automatic Conveyor: Optional device for materials up to 3000 mm long.
- Rotary Engraving: Compatible with RA2 Pro for glasses, mugs, and rings.
- Riser Base: Increases height to engrave objects up to 125 mm high.
- Smart Air Assist: Automatically adjusts airflow for cleaner cutting results.
Technical Specification
| xTool S1 20W Specification | |
|---|---|
| Machine Type | Diode Laser Machine |
| Engraving Area | 498 × 319 mm |
| Laser Output Power | 20 W |
| Routing Speed | 600 mm/s |
| Max. Workpiece Height | 125 mm (with Riser Base) |
| Software | xTool Creative Space, LightBurn |
| Connectivity | USB, Wi-Fi |
| Weight / Dimensions | 20.0 kg / 765 × 561 × 183 mm |
Buy xTool S1 20W in Ukraine
The 3DDevice store offers a wide range of Laser Engravers and Cutters with delivery throughout Ukraine. To buy the xTool S1 20W and receive a professional consultation, contact us via the Contacts page.
