3D scanner Revopoint Range | Standard Package

51 900 грн.

  • Two spaced infrared cameras provide a wide scanning angle.
  • Working distance – 300 – 800 mm.
  • Single-frame Precision – up to 0.1 mm.
  • Single Capture Range – 360×650 at a distance of 600 mm.
  • Scanning speed – up to 18 frames/s.
  • Scans in color.
  • Suitable for scanning large objects.
  • Compact design – only 210 g.

➤ 3DDevice is an authorized distributor of Revopoint in Ukraine

Category: Tag:

Description

Buy Revopoint Range wide-range 3D scanner in Ukraine

Looking for a budget-friendly handheld 3D scanner to create 3D copies of large objects? Introducing the Revopoint Range 3D scanner, whith powerful wide-range infrared projector that provides a scanning distance of up to 800 mm while maintaining an impressive single-frame accuracy of up to 0.1 mm. The Revopoint Range is your powerful tool for scanning large objects: cars, furniture, industrial parts, and even human scanning is within its reach!



The main about Range

  • Working distance – 300 – 800 mm.
  • Single frame accuracy – up to 0.1 mm.
  • Single frame capture size – 360×650 at a distance of 600 mm.
  • Scanning speed – up to 18 frames per second.
  • RGB camera.
  • Compact design – only 210 g.



Range 3D scanner – large scans, large objects

The Revopoint Range wide-angle 3D scanner is your gateway to affordable and highly accurate 3D scanning of large objects. The scanner’s infrared projector can scan from a distance of up to 800 mm, with a single frame accuracy of up to 0.1 mm, making the Range a powerful tool for scanning large objects. Auto and motorcycle equipment, furniture, large toys, statues, paintings, machinery and industrial equipment, as well as human scans – all of these can be quickly scanned by Revopoint Range and create an accurate 3D model.



Large surface scanning area

Single capture range of 360×650 at 600 mm. Scanning cars, furniture, people and many other large objects has never been more accessible.



Wide-range 3D scanner Revopoint Range



Precise 3D models

With a single-frame accuracy of 0.1 mm and a point-to-point distance of 0.1 mm, RANGE’s new dual aspherical lens IR cameras reduce image aberrations and ensure that microstructured infrared light hits the sensors evenly.

Whether for reverse engineering, quality control, or design, the Range scanner’s single-frame accuracy of 0.1 mm ensures reliably accurate models.



Fast and smooth scanning

With scanning speeds of up to 18 frames per second, you can move the Range comfortably and smoothly during scanning. The integration of a proprietary chip design and advanced algorithms allows for even smoother frame stitching, which improves scanning efficiency.



Fast, smooth scanning of the Revopoint Range



True portable 3D scanning

Enjoy the complete freedom of handheld scanning with the Power Bank Handle, which provides power to the Range for up to 2 hours. And thanks to the detachable tripod, Range can easily switch between turntable scanning and portable handheld 3D scanning modes, ready for outdoor use.

This thoughtfully designed 3D gadget features stationary and mobile scanning modes, an adjustable holder angle, a telescopic tripod with adjustable height, and a mobile holder that can easily adapt to different smartphone widths.



True portable 3D scanning



A color scanner to capture a colorful world

The RGB camera of the Range 3D scanner captures the color of an object as it scans and is ready to be merged with the 3D model after the data is combined to create accurate, full-color, near-realistic 3D models.



RGB camera of the Range 3D scanner



Optimal automotive modeling

Typically, creating custom or aftermarket parts for automobiles requires a lot of time spent manually measuring and modeling to ensure the accuracy of the parts. But with the Range scanner, you can quickly create accurate 3D models that can be used in CAD, even when scanning complex geometries.



Complete human scans in less than 2 minutes

With fast full body scanning, you can easily create simple 3D models of the whole body for video games, fashion design, augmented reality, and virtual reality in less than two minutes. You can also print a nearly realistic miniature model on the 3D printer that will make a unique gift or a wedding cake topper. Using the large rotary table, you can do this even faster.

The scanner easily reproduces all elements of human clothing, skin, and hair: seams, folds, wrinkles, and even pores. The 3D scans are ready for use in AR/VR or fashion design.



Turntable

The Revopoint Range Premium Package includes a heavy-duty rotary table. Its robust design can withstand a maximum load of 200 kg and rotates at a speed of 35-90 seconds per revolution. The table’s powerful motor ensures smooth rotation even under maximum load and is designed for up to 3000 hours of trouble-free operation. The rotation speed can be easily adjusted using the remote control or the app.



Rotary table for 3D human scanning



Scan from your mobile with Revo Scan

For independent mobile scanning on the go, you can quickly connect your phone or tablet to your Range scanner using the Revo Scan app on your Android or iOS device. Once you’re done scanning, quickly export your 3D models or designs to the desktop version of Revo Scan for further processing.



Revo Scan - Revopoint Range 3D Scanner



Compatible with industry-leading applications

Easily import your 3D model into a large list of well-known 3D digital data programs.



Standard package: everything you need to start printing

  • 3D scanner
  • Phone holder
  • Quick mount kit
  • Type C adapter
  • USB cable (Micro B to Type A)
  • Inspection certificate
  • Power Bank
  • Tripod
  • Mobile cable 2-in-1



Contents of the Premium Package: heavy-duty rotary table in the set

  • Standard Package
  • Large rotary table



Specifications

Light SuorceInfrared structured light with dual camera
Scanning range (mm)360 × 650 at a distance of 600 mm
Working distance (mm)300 – 800
Scanner typePortable
Color ScanningYes
Safety ClassInfrared light CLASS I
Minimum scanning volume (m3)min 0.07 × 0.07 × 0.07
Scan speed (fps)12 – 18
Scanning accuracy (mm)Up to 0.1
Distance Between Points (mm)Up to 0.1
Positioning methodsFeatures, Markers
Supported File TypesPLY, OBJ, STL
ConnectionUSB 3.0, Wi-Fi 5.1, Bluetooth 4.1
System RequirementsWindows 8/10/11 (64-bit), Android, iOS, macOS
Producing countryChina
Warranty period (months)12
Net weight (kg)0.21
Dimensions Net (mm)295 × 42 × 28.2



Meet the Revopoint Range in Ukraine, video:



Buy Revopoint Range wide-angle 3D scanner in Ukraine

In the 3DDevice store, you can buy a wide range of portable 3D scanners from different manufacturers. Our experts will help you choose a scanning device for your specific needs. Delivery throughout Ukraine.
